Bluetooth Wii Remote

#include <Wire.h>
#include <Adafruit_Sensor.h>
#include <Adafruit_BNO055.h>
#include <utility/imumaths.h>
#include <HijelHID_BLEMouse.h>
#include <math.h>

Adafruit_BNO055 bno = Adafruit_BNO055(55, 0x28);
HijelBLEMouse mouse("ESP32 Air Pointer", "Joey", 100);

// ===== USER CONFIG =====
const int SCREEN_WIDTH  = 3440;
const int SCREEN_HEIGHT = 1440;

// ===== BUTTON INPUTS =====
const int BUTTON_UP_PIN    = 13;
const int BUTTON_DOWN_PIN  = 14;
const int BUTTON_LEFT_PIN  = 27;
const int BUTTON_RIGHT_PIN = 26;

// Higher = faster button panning
const float buttonPanStep = 4.0f;

float buttonOffsetX = 0.0f;
float buttonOffsetY = 0.0f;

// ===== ORIENTATION OFFSETS =====
float offsetYaw = 0.0f;
float offsetPitch = 0.0f;
float offsetRoll = 0.0f;

// ===== VIRTUAL CURSOR POSITION =====
// This represents where the code believes the cursor is,
// relative to screen center.
float virtualX = 0.0f;
float virtualY = 0.0f;

// ===== SCREEN MAPPING =====
// How many degrees of controller motion map to the screen edge.
const float yawEdgeDeg = 60.0f;
const float pitchEdgeDeg = 33.0f;

// Center calibration for macOS / display scaling.
const float CENTER_X_SCALE = 1.35f;
const float CENTER_Y_SCALE = 1.35f;

// ===== FILTERING =====
const float yawDeadzoneDeg = 0.4f;
const float pitchDeadzoneDeg = 0.4f;

const float maxYawJumpDeg = 35.0f;
const float maxPitchJumpDeg = 35.0f;

float lastValidYaw = 0.0f;
float lastValidPitch = 0.0f;

float smoothYaw = 0.0f;
float smoothPitch = 0.0f;

// Lower = smoother but slower. Higher = faster but shakier.
const float angleSmoothing = 0.18f;

// ===== CURSOR BEHAVIOR =====
// How aggressively cursor moves toward desired absolute position.
const float followGain = 0.11f;

// Maximum mouse counts sent per update.
const int maxMoveStep = 18;

// If error is smaller than this, stop moving.
const float stopThreshold = 1.5f;

// Compensation for OS mouse scaling / acceleration.
// Tune this if virtual cursor and real cursor slowly separate.
const float virtualMovementScale = 0.45f;

// ===== TIMING =====
const unsigned long updateMs = 5;
unsigned long lastUpdate = 0;
unsigned long lastPrint = 0;

// ===== HELPERS =====
float wrapAngle180(float deg) {
  while (deg > 180.0f) deg -= 360.0f;
  while (deg < -180.0f) deg += 360.0f;
  return deg;
}

float clampFloat(float value, float minVal, float maxVal) {
  if (value < minVal) return minVal;
  if (value > maxVal) return maxVal;
  return value;
}

int clampInt(int value, int minVal, int maxVal) {
  if (value < minVal) return minVal;
  if (value > maxVal) return maxVal;
  return value;
}

float applyDeadzone(float value, float deadzone) {
  if (fabs(value) < deadzone) return 0.0f;
  return value;
}

float lowPass(float previous, float current, float alpha) {
  return previous + alpha * (current - previous);
}

float filterYaw(float newYaw) {
  if (isnan(newYaw) || isinf(newYaw)) {
    return lastValidYaw;
  }

  float yawDelta = wrapAngle180(newYaw - lastValidYaw);

  if (fabs(yawDelta) > maxYawJumpDeg) {
    offsetYaw = wrapAngle180(offsetYaw + yawDelta);
    return lastValidYaw;
  }

  lastValidYaw = newYaw;
  return newYaw;
}

float filterPitch(float newPitch) {
  if (isnan(newPitch) || isinf(newPitch)) {
    return lastValidPitch;
  }

  float pitchDelta = newPitch - lastValidPitch;

  if (fabs(pitchDelta) > maxPitchJumpDeg) {
    offsetPitch = wrapAngle180(offsetPitch + pitchDelta);
    return lastValidPitch;
  }

  lastValidPitch = newPitch;
  return newPitch;
}

void moveMouseCounts(int totalDx, int totalDy) {
  while (totalDx != 0 || totalDy != 0) {
    int stepX = 0;
    int stepY = 0;

    if (totalDx > 0) stepX = min(totalDx, 100);
    if (totalDx < 0) stepX = max(totalDx, -100);

    if (totalDy > 0) stepY = min(totalDy, 100);
    if (totalDy < 0) stepY = max(totalDy, -100);

    mouse.move(stepX, stepY);

    totalDx -= stepX;
    totalDy -= stepY;

    delay(3);
  }
}

// ===== HARD CURSOR CENTERING =====
void moveCursorToCenter() {
  if (!mouse.isPaired()) {
    Serial.println("Mouse not paired. Cursor was not centered.");
    return;
  }

  Serial.println("Centering cursor...");

  moveMouseCounts(-12000, -12000);
  delay(150);

  int centerXCounts = (int)lround((SCREEN_WIDTH / 2.0f) * CENTER_X_SCALE);
  int centerYCounts = (int)lround((SCREEN_HEIGHT / 2.0f) * CENTER_Y_SCALE);

  moveMouseCounts(centerXCounts, centerYCounts);
  delay(150);

  virtualX = 0.0f;
  virtualY = 0.0f;

  Serial.println("Cursor centered.");
}

// ===== RECENTER =====
void recenterFromCurrent() {
  sensors_event_t event;
  bno.getEvent(&event);

  offsetYaw = event.orientation.x;

  // Swapped pitch/roll mapping from your current setup.
  offsetRoll = event.orientation.y;
  offsetPitch = event.orientation.z;

  lastValidYaw = 0.0f;
  lastValidPitch = 0.0f;

  smoothYaw = 0.0f;
  smoothPitch = 0.0f;

  virtualX = 0.0f;
  virtualY = 0.0f;

  buttonOffsetX = 0.0f;
  buttonOffsetY = 0.0f;

  moveCursorToCenter();

  lastUpdate = millis();

  Serial.println("Recenter complete.");
}

// ===== SETUP =====
void setup() {
  Serial.begin(115200);
  delay(1000);

  Serial.println("BNO055 Absolute Pointer Starting...");

  pinMode(BUTTON_UP_PIN, INPUT_PULLUP);
  pinMode(BUTTON_DOWN_PIN, INPUT_PULLUP);
  pinMode(BUTTON_LEFT_PIN, INPUT_PULLUP);
  pinMode(BUTTON_RIGHT_PIN, INPUT_PULLUP);

  Wire.begin(21, 22);
  Wire.setClock(400000);

  if (!bno.begin()) {
    Serial.println("BNO055 NOT detected.");
    while (1) {
      delay(100);
    }
  }

  bno.setExtCrystalUse(true);
  mouse.begin();

  delay(300);
  recenterFromCurrent();

  Serial.println("Ready. Press 'c' to recenter.");
}

// ===== LOOP =====
void loop() {
  while (Serial.available()) {
    char input = Serial.read();

    if (input == 'c' || input == 'C') {
      recenterFromCurrent();
    }
  }

  if (millis() - lastUpdate < updateMs) {
    return;
  }
  lastUpdate = millis();

  sensors_event_t event;
  bno.getEvent(&event);

  float yaw = event.orientation.x;

  // Swapped pitch/roll mapping from your current setup.
  float roll = event.orientation.y;
  float pitch = event.orientation.z;

  float rawRelYaw = wrapAngle180(yaw - offsetYaw);
  float rawRelPitch = wrapAngle180(pitch - offsetPitch);
  float relRoll = wrapAngle180(roll - offsetRoll);

  float relYaw = filterYaw(rawRelYaw);
  float relPitch = filterPitch(rawRelPitch);

  relYaw = applyDeadzone(relYaw, yawDeadzoneDeg);
  relPitch = applyDeadzone(relPitch, pitchDeadzoneDeg);

  smoothYaw = lowPass(smoothYaw, relYaw, angleSmoothing);
  smoothPitch = lowPass(smoothPitch, relPitch, angleSmoothing);

  // Convert controller angle directly to desired screen position.
  // This is the Wii-style behavior: point angle maps to screen location.
  float halfScreenX = SCREEN_WIDTH / 2.0f;
  float halfScreenY = SCREEN_HEIGHT / 2.0f;

  // ===== BUTTON-BASED TARGET POSITION OFFSET =====
  // Buttons are active LOW because INPUT_PULLUP is used.
  // Holding a button continuously shifts the target position.
  if (digitalRead(BUTTON_UP_PIN) == LOW) {
    buttonOffsetY -= buttonPanStep;
  }

  if (digitalRead(BUTTON_DOWN_PIN) == LOW) {
    buttonOffsetY += buttonPanStep;
  }

  if (digitalRead(BUTTON_LEFT_PIN) == LOW) {
    buttonOffsetX -= buttonPanStep;
  }

  if (digitalRead(BUTTON_RIGHT_PIN) == LOW) {
    buttonOffsetX += buttonPanStep;
  }

  // No clamp here: button offsets are allowed to keep moving beyond
  // the internal screen bounds so the cursor will not hit an artificial wall.

  float targetX = ((smoothYaw / yawEdgeDeg) * halfScreenX) + buttonOffsetX;
  float targetY = (-(smoothPitch / pitchEdgeDeg) * halfScreenY) + buttonOffsetY;

  // No target clamp here: removing the artificial internal screen boundary.
  // The actual operating system cursor edge will be the only real boundary.

  float errorX = targetX - virtualX;
  float errorY = targetY - virtualY;

  int dx = 0;
  int dy = 0;

  if (fabs(errorX) > stopThreshold) {
    dx = clampInt((int)lround(errorX * followGain), -maxMoveStep, maxMoveStep);
  }

  if (fabs(errorY) > stopThreshold) {
    dy = clampInt((int)lround(errorY * followGain), -maxMoveStep, maxMoveStep);
  }

  if (mouse.isPaired() && (dx != 0 || dy != 0)) {
    mouse.move(dx, dy);

    virtualX += dx * virtualMovementScale;
    virtualY += dy * virtualMovementScale;

    // No virtualX/virtualY clamp here: removing the artificial internal screen boundary.
  }

  if (millis() - lastPrint > 150) {
    lastPrint = millis();

    Serial.print("RawYaw:");
    Serial.print(rawRelYaw, 1);
    Serial.print(" Yaw:");
    Serial.print(relYaw, 1);
    Serial.print(" SmoothYaw:");
    Serial.print(smoothYaw, 1);

    Serial.print(" RawPitch:");
    Serial.print(rawRelPitch, 1);
    Serial.print(" Pitch:");
    Serial.print(relPitch, 1);
    Serial.print(" SmoothPitch:");
    Serial.print(smoothPitch, 1);

    Serial.print(" Roll:");
    Serial.print(relRoll, 1);

    Serial.print(" | ButtonOffsetX:");
    Serial.print(buttonOffsetX, 0);
    Serial.print(" ButtonOffsetY:");
    Serial.print(buttonOffsetY, 0);

    Serial.print(" | TargetX:");
    Serial.print(targetX, 0);
    Serial.print(" VirtualX:");
    Serial.print(virtualX, 0);

    Serial.print(" | TargetY:");
    Serial.print(targetY, 0);
    Serial.print(" VirtualY:");
    Serial.print(virtualY, 0);

    Serial.print(" | dx:");
    Serial.print(dx);
    Serial.print(" dy:");
    Serial.println(dy);
  }
}
